A telescope with a concave lens that focuses internally is called an internal focusing telescope. In an internal focusing telescope, the objective and eyepiece are kept at a fixed distance and focusing is achieved by a double concave lens mounted in a short tube that slides axially between the eyepiece and the objective. Enables and focuses with an associated rack and pinion arrangement. PatchThe objective is a compound lens consisting of a front double convex lens made of crown glass and the back concave-convex lens made of flint glass . The two lenses when cemented together with balsam at their common surface are generally known as achromatic lens. In such lenses, the spherical and chromatic aberrations known as optical serious defects are practically eliminated.
The eyepiece is composed of two plane convex lenses with a distance of two-third the local distance. The convex surfaces are turned towards one another. The Ramsden eyepiece is used in most surveying telescopes.
To provide a definite line of sight, horizontal and vertical cross hairs held in a flat metal ring called reticule are fitted into the diaphragm. The diaphragm is a flanged metal ring held in the telescope barrel by four capstan headed screws. With the help of the capstan headed screws, the position of the cross hairs inside the tube can be adjusted slightly, horizontally, vertically and rotationally. The hairs or lines are arranged in different ways as shown in .
The telescope is used to read the levelling staff and the cross hairs enable the surveyor to take the staff reading.
