Concrete mixing for reinforced concrete work and medium or large scale concrete work is always done by machine. Machine mixing is not only efficient and fast but also economical when the quantity of concrete is high.
Concrete mixers can be classified as batch mixers and continuous mixers. Batch mixers prepare concrete batch by batch at intervals while continuous mixers prepare concrete without stopping. Continuous mixers are used in large works such as dams. In general concrete work, batch mixers are used. Batch mixers can be pan type or drum type. Drum type can be further classified as tilting, non-tilting and reversing or forced action type.
To get better efficiency, the sequence of charging the loading skip is as described below. Firstly, about half the quantity of coarse aggregate is placed on the skip over which about half the quantity of fine aggregate is poured. On that the full quantity of cement is poured, over which the remaining portion of coarse and fine aggregate is deposited in sequence. This prevents spilling of aggregate while discharging into the drum and also the blowing away of cement in windy weather.
Before the loading skip is discharged into the drum, about 25 per cent of the total water required for mixing is introduced into the mixer drum to wet the drum and to prevent any cement from sticking to the blades or the bottom of the drum. Immediately on discharging the dry materials, the remaining 75 per cent of water is added to the drum.
Concrete mixers are generally designed to run at a speed of 15–20 revolutions per minute. On the site, the normal tendency is to reduce the mixing time to increase the outturn. This results in poor quality of concrete. On the other hand, if the concrete is mixed for a comparatively longer time, it is uneconomical from the point of view of rate of production of concrete and fuel consumption. Therefore, it is of importance to mix the concrete for such a duration that will give optimum benefit. It is seen that the quality of concrete in terms of compressive strengths will increase with increase in the time of mixing, but for mixing time beyond 2 minutes the increase in compressive strength is not very significant.
Concrete mixers are often used continuously without stopping for several hours for mixing and placing. It is of utmost importance that a mixer should not stop in between the concreting operation. For this, the mixer must be well maintained. The mixer is placed on the site at a firm and levelled platform. The drum and blades must be kept clean at the end of the concreting operation. The drum must be kept in tilting position or kept covered when not in use to prevent the collection of rainwater. The skip is operated carefully and it must be provided with proper cushion such as sand bags.
